DELPHI TC3598 Part Description
Manufacturer
Product Description
Suspension Stabilizer Bar Link
Features & Benefits
- Sway bar links manufactured with ultrasonic molding to help prevent future weld breakage
- Delphi sway bar links are fatigue tested to avoid failure
- Delphi machines to micron tolerances to guarantee durability and smooth joint operation
- Anti Corrosion protection applied to each part for optimum corrosion prevention and enhanced aesthetics
DELPHI TC3598 Specifications
Product Attributes
| Item Grade | Standard Replacement |
| Position(s) | Front |
| Material | Outer Sleeve - Aluminum |
| Bushing Outside Diameter | 1.437 IN |
| Bushing Outside Diameter | 36.50 MM |
| Bushing Color | Black |
| Length | 218.00 MM |
| Length | 8.583 IN |
| Bushings Included | Yes |
| Dust Boot Included | No |
| Sleeve Inside Diameter | 0.402 IN |
| Sleeve Inside Diameter | 10.2 MM |
| Sleeve Length | 1.26 IN |
| Sleeve Length | 32 MM |
| Width | 1.26 IN |
| Washers Included | No |
| Height | 48.00 MM |
| Height | 1.890 IN |
| Grade Type | Performance |
| Bolts Included | No |
| Housing Material | Aluminum |
| Greaseable | No |
| Weight | 0.44 lb |
| Bushing Material | Rubber |
| Distance Between Mounting Holes | 170.00 MM |
| Locking Nuts Included | No |
| Bushing Inside Diameter | 23.00 MM |
| Bushing Inside Diameter | 0.906 IN |
| Width | 32 MM |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708807000 |
| Harmonized Tariff Code (HTS) | 8708806590 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| Country of Origin (Primary) | TR |
| UPC | 00689604297506 |
| VMRS Code | 016004006 |
| UNSPSC | 25172001 |
DELPHI TC3598 Cross References
| Brand | Part Number |
|---|---|
| Audi | 4G0 411 317 A, 4M0 411 317 |
| Beck/Arnley | 101-8310 |
| CORTECO | 49399179 |
| DORMAN | SL12155, SL12155PR |
| MEVOTECH | MS70861 |
| MEYLE | 116 060 0029, 1160600029S, 116 060 0034, 1160600041/S, 1160600049 |
| MOOG Chassis Products | K750359 |
| N/A | K700618, MS70861 |
| Porsche | 4G0 411 317 A, 4M0 411 317 |
| URO | 4M0411317 |
| VAICO | V103181 |
DELPHI TC3598 Fits Vehicles
- Audi e-tron S (2022)
- Audi e-tron S Sportback (2022)
- Audi SQ5 Sportback (2021-2022)
- Audi Q5 Sportback (2021-2022)
- Audi RS7 Sportback (2021-2022)
- Audi SQ8 (2020-2022)
- Audi SQ7 (2020-2022)
- Audi RS6 Avant (2021-2022)
- Audi RS Q8 (2020-2022)
- Audi S7 Sportback (2020-2022)
- Audi Q5 PHEV (2020-2022)
- Audi e-tron Sportback (2020-2022)
- Audi A6 allroad (2020-2022)
- Audi A7 Sportback (2019-2022)
- Audi Q8 (2019-2022)
- Audi e-tron Quattro (2019-2022)
- Porsche Cayenne (2019-2021)
- Audi A4 allroad (2017-2021)
- Audi Q7 (2017-2022)
- Audi S5 (2016-2017)
- Audi S4 (2016-2021)
- Audi SQ5 (2016-2022)
- Audi A4 Quattro (2016-2021)
- Audi A5 Quattro (2016-2017)
- Audi Q5 (2016-2022)
- Audi A4 (2016-2020)
- Audi A7 Quattro (2016-2018)
- Audi A6 Quattro (2016-2022)
- Audi A6 (2016-2018)
- Audi S8 (2015-2018, 2020-2022)
- Audi A8 Quattro (2015-2022)
- Porsche Macan (2015-2021)
- Audi RS7 (2014-2018)
- Audi S6 (2013-2014, 2016-2018, 2020-2022)
- Audi S7 (2013-2014, 2016-2018)
