(888) 312-8812 Login SignupCENTRIC 320.33097H Centric GCX Rotor with Full Coating and High Carbon Content
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
CENTRIC 320.33097H Part Description
Manufacturer
Product Description
Centric GCX Rotor with Full Coating and High Carbon Content
Features & Benefits
- RS200 Coating our exclusive corrosion resistant coating for longer life and good looks; Iron Formulation Enhanced iron & high carbon metallurgies means the right rotor for your car; Operational Efficiency Full coverage with 80% fewer SKUs
- For the best corrosion resistance
- RS200™ Zinc-Aluminum Rich Coating
- Optimal Surface Finish
- For consistent and confident braking from the first stop
- Carbon Enhanved Advanced Metallurgy
- For optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- For heat capacity and strength
- Low Initial Lateral Run-Out
- For smooth vibration free stopping
- Precision Balance
- For vibration free performance
CENTRIC 320.33097H Specifications
Product Attributes
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Product Grade [cntrc] | Premium |
| Misc Holes [cntrc] | 1 |
| Weight [cntrc] Lbs | 10.850 |
| Weight [cntrc] Kgs | 4.930 |
| Disc Mounting [cntrc] | Floating |
| Discard Thickness | 0.394 IN |
| Stud/Lug Hole Diameter | 0.591 IN |
| Stud/Lug Hole Diameter | 15.000 MM |
| Stud/Lug Hole Quantity | 5 |
| Mounting Bolt Hole Circle Diameter | 4.417 IN |
| Mounting Bolt Hole Circle Diameter | 112.200 MM |
| Center Hole Diameter | 2.677 IN |
| Center Hole Diameter | 68.000 MM |
| Bearings Included | No |
| Solid Or Vented Type Rotor | Solid |
| Surface Type | Smooth |
| ABS Tone Ring Included | No |
| Outside Diameter | 287.000 MM |
| Outside Diameter | 11.299 IN |
| Overall Height | 1.417 IN |
| Overall Height | 36.000 MM |
| Hat Finish | Coated |
| Disc Finish | Fully Coated |
| Nominal Thickness | 12.000 MM |
| Nominal Thickness | 0.472 IN |
| Discard Thickness | 10.000 MM |
Additional Information
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00889590386820 |
CENTRIC 320.33097H Cross References
CENTRIC 320.33097H Fits Vehicles
- Seat Exeo (2011)
- Audi A4 Quattro (2005-2009)
- Audi A4 (2001-2009)
