CENTRIC 320.34086H Part Description
Manufacturer
Product Description
Centric GCX Rotor with Full Coating and High Carbon Content
Features & Benefits
- RS200 Coating our exclusive corrosion resistant coating for longer life and good looks; Iron Formulation Enhanced iron and high carbon metallurgies means the right rotor for your car; Operational Efficiency Full coverage with 80% fewer SKUs
- For the best corrosion resistance
- RS200™ Zinc-Aluminum Rich Coating
- Optimal Surface Finish
- For consistent and confident braking from the first stop
- Carbon Enhanved Advanced Metallurgy
- For optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- For heat capacity and strength
- Low Initial Lateral Run-Out
- For smooth vibration free stopping
- Precision Balance
- For vibration free performance
CENTRIC 320.34086H Specifications
Product Attributes
| Misc Holes [cntrc] | 1 |
| Weight [cntrc] Lbs | 21.850 |
| Product Grade [cntrc] | Premium |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Weight [cntrc] Kgs | 9.930 |
| Disc Mounting [cntrc] | Floating / DIH |
| Vane Style [cntrc] | Straight |
| Discard Thickness | 0.882 IN |
| Discard Thickness | 22.400 MM |
| Nominal Thickness | 23.800 MM |
| Nominal Thickness | 0.937 IN |
| Disc Finish | Fully Coated |
| Hat Finish | Coated |
| Overall Height | 74.000 MM |
| Overall Height | 2.913 IN |
| Outside Diameter | 344.600 MM |
| Outside Diameter | 13.567 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Nominal Drum Diameter | 7.283 IN |
| Nominal Drum Diameter | 185.000 MM |
| Bearings Included | No |
| Center Hole Diameter | 3.106 IN |
| Center Hole Diameter | 78.900 MM |
| Mounting Bolt Hole Circle Diameter | 120.000 MM |
| Mounting Bolt Hole Circle Diameter | 4.724 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 16.700 MM |
| Stud/Lug Hole Diameter | 0.657 IN |
Additional Information
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00889590387421 |
CENTRIC 320.34086H Cross References
CENTRIC 320.34086H Fits Vehicles
- BMW 760i (2005-2006)
- BMW 760Li (2005-2008)
- BMW 750Li (2006-2008)
- BMW 750i (2006-2008)
