RAYBESTOS 982292 Raybestos Specialty - Street Performance Coated Brake Rotor

982292 by RAYBESTOS - Raybestos Specialty - Street Performance Coated Brake Rotor
RAYBESTOS
SHIPS MONDAY

$116.49

Limited availability at this price!

In Stock

Get it by Thursday, Feb 12
No Hassle Return Policy Details
Free Economy shipping on orders over $499 details
Orders placed over the weekend will ship the following business day

RAYBESTOS 982292 Part Description

Manufacturer

RAYBESTOS

Product Description

Raybestos Specialty - Street Performance Coated Brake Rotor

Application Summary

2023-2018 Toyota Camry Front, 2021-2019 Toyota RAV4 Front, 2023-2019 Lexus ES350 Front, 2023-2021 Toyota Venza Front, 2022-2020 Toyota C-HR Front, 2022-2019 Toyota Avalon Front, 2023-2019 Lexus UX250h Front

Features & Benefits

  • Application Specific Enhanced Iron
  • Raybestos® Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
  • Raybestos(R) Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
  • Cooling Vanes
  • The cooling vanes match OE configurations and provide optimal cooling and reduced fade.
  • Application Specific Coating
  • Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0® coating on the entire rotor
  • Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0(R) coating on the entire rotor
  • Black fusion coating on the rotor hat and Grey Fusion 4.0® coating on the rotor inboard surface and cooling vanes
  • Black fusion coating on the rotor hat and Grey Fusion 4.0(R) coating on the rotor inboard surface and cooling vanes
  • Turned Finish
  • Turned finish minimizes noise and improves responsiveness for smoother stops.
  • S-Groove Slot
  • Depending on the application, some Raybestos® Performance Rotors are designed with a patented S-Groove Slot.
  • Depending on the application, some Raybestos(R) Performance Rotors are designed with a patented S-Groove Slot.

RAYBESTOS 982292 Specifications

Product Attributes

ABS Tone Ring Included No
Center Hole Diameter 2.441 IN
Center Hole Diameter 62 MM
Conventional Or Drum-In-Hat Type Rotor Conventional
Directional or Non-Directional Brake Surface Non-Directional
Discard Thickness 0.984 IN
Discard Thickness 25 MM
Harmonize Code 8708.30.5030
Inside Diameter 7.815 IN
Inside Diameter 198.5 MM
Material Cast Iron
Mounting Bolt Hole Circle Diameter 4.5 IN
Mounting Bolt Hole Circle Diameter 114.3 MM
Mounting Bolt Hole Diameter 0.571 IN
Mounting Bolt Hole Diameter 14.5 MM
Mounting Bolt Hole Quantity 5
Nominal Thickness 1.102 IN
Nominal Thickness 28 MM
Outside Diameter 12.008 IN
Outside Diameter 305 MM
Overall Height 1.937 IN
Overall Height 49.2 MM
Salability Restrictions No
Solid Or Vented Type Rotor Vented
Stud/Lug Hole Quantity 5
Surface Type Smooth
UNSPSC Code 25171715

Additional Information

Country of Origin (Primary) CN
Canadian Harmonizing Tariff Code 8708309990
Harmonized Tariff Code (HTS) 8708305030
UPC 00887213310801

RAYBESTOS 982292 Cross References

BrandPart Number
ADVANCE AUTO PARTSYH653460P
ADVICSA6F1062
AUTOXTRAAX901636
AutoZone71937DL, 71937DG
AutoxtraAX901636P
BrakeBest922278RGS
Brembo09.D979.11
CENTRIC120.44202, 121.44202, 126.44202SL, 127.44202L, 127.44202R, 128.44202L, 128.44202R, 320.44202, 320.44204
Centric Parts120.44202, 121.44202, 126.44202SL, 127.44202L, 127.44202R, 128.44202L, 128.44202R, 320.44202
DURA CORPBR901636
DuraGoBR901636
Dynamic Friction Company604-76154
Lexus4351206200, 4351276010
MAGMA PRODUCTSPSR565193
Qualis44901
TOYOTA4351206170, 4351206200, 4351233150, 4351276010
TopNotchTN982292GEO
WAGNER BRAKEBD180796
WORLDPAC1407-653460, 1427-690539
Wagner BrakeBD180796E
Winhere6622278

RAYBESTOS 982292 Fits Vehicles

  • Lexus UX300h (2025)
  • Toyota Prius (2025)
  • Toyota Prius Prime (2023-2024)
  • Toyota Prius AWD-e (2023-2024)
  • Toyota Corolla Cross (2022-2025)
  • Lexus ES250 (2021-2025)
  • Toyota Venza (2021-2024)
  • Toyota C-HR (2020-2022)
  • Lexus UX250h (2019-2024)
  • Lexus UX200 (2019-2022)
  • Lexus ES350 (2019-2025)
  • Lexus ES300h (2019-2025)
  • Toyota RAV4 (2019-2025)
  • Toyota Avalon (2019-2022)
  • Toyota Camry (2018-2024)
