DORMAN BJ74305 Part Description
Manufacturer
Product Description
Suspension Ball Joint
Application Summary
Pontiac Vibe 2010-03, Scion tC 2010-05, Toyota Corolla 2019-09, Toyota Matrix 2014-03
Features & Benefits
- Direct replacement - fits and performs like the original equipment on specific vehicles
- Reliable fit - precision-engineered to match the design and dimensions of original components
- Durable construction - manufactured to strict standards using sturdy, safe materials
- Rigorously tested - thorough quality control measures ensure longevity
Suspension, Ball, Joint, Joints, Balls, Suspensions
DORMAN BJ74305 Specifications
Product Attributes
| Material | Acero |
| Stud Thread Diameter | 14 MM |
| Castle Nut Included | Oui |
| Suspension Grade Type | Reemplazo estándar |
| Cotter Pin Hole | Oui |
| Mounting Hardware Included | Oui |
| Mounting Hole Quantity | 3 |
| Adjustable | Non |
| Greaseable | Non |
| Stud Type | Cono |
| Mounting Type | A presión |
| Dust Boot Material | Policloropreno |
| Attachment Type | Perno activado |
| Bearing Material | Polímero |
| Bolts/Studs Included | Oui |
| Housing Press Fit Diameter | 35 mm |
| Package Contents | 3 Nuts |
| Thread Pitch | 1.5 mm |
| Length | 111 MM |
| Color | Gris |
| Width | 59 MM |
| Type | Roscado |
| Height | 85.03 MM |
| Wrench Size | 12 mm MM |
| Maximum Outside Diameter | 61 MM |
| Grease Fitting Included | Non |
| Bushings Included | Non |
| Dust Boot Included | Oui |
| Ball Joint Assembly | Oui |
| Cotter Pin Included | Non |
| Washers Included | Non |
| Nuts Included | Oui |
| Stud Thread Length | 35.5 MM |
| Bushing Quantity | 0 |
| Mounting Bolts Included | Non |
| Mount Plate Included | Non |
| Tapered Stud | Oui |
| Stud Taper Per Foot | 2 IN |
| Stud Tapered End 2 Diameter | 22 MM |
| Stud Tapered End 1 Diameter | 27.2 MM |
| Stud Thread Pitch | 1.5 MM |
| Articulación de rótula instalada | Sí |
| Ball Joint Installed | Oui |
| Bushing Included | Non |
| Contenidos del paquete | 3 tuercas |
| Diámetro del acoplado a presión de la caja | 35mm mm |
| Housing Press Fit Diameter | 35 mm MM |
| Pernos/argollas incluidos | Sí |
| Thread Pitch | 1.5 mm mm |
| Nuts Included | Oui |
| Stud Thread Pitch | 1.5 mm MM |
| Stud Thread Diameter | 14 mm MM |
| Paso de rosca | 1,5mm MM |
| Espacio de la rosca del espárrago | 1,5mm MM |
| Diámetro de la rosca de la argolla | 14 mm MM |
Additional Information
| Country of Origin (Primary) | TH |
| Harmonized Tariff Code (Schedule B) | 8708807000 |
| Warranty Special UOM | LF |
| Warranty Special | Limited |
| UPC | 00843295055542 |
| VMRS Code | 016001015 |
| UNSPSC | 25174203 |
DORMAN BJ74305 Cross References
| Brand | Part Number |
|---|---|
| 555 | SB-3962 |
| ACDelco | 45D2327, 46D2327A |
| ADVANTAGE | 46D2327A |
| Beck/Arnley | 1015320, 101-5320 |
| C-Tek | 611.44036, 611.62017 |
| Centric Parts | 610.44036, 610.62017, 611.44036, 611.62017 |
| DELPHI | TC8291 |
| DORMAN | 535-599, 534-017, 536-366 |
| Delphi | TC1779 |
| General Motors | 19184280, 88972115, 4333009190 |
| MEVOTECH | MK80301, MK80595 |
| MOOG | K80595, K500175, K500040 |
| MOOG Chassis Products | K500040, K500175, K80595 |
| Mcquay-Norris | FA2243 |
| Mevotech Original Grade | GK80595, GK80301 |
| Mevotech Supreme | MK80301, MK80595, MS50521 |
| QUICK STEER | K500175, K80595, K500040 |
| QuickSteer | K500040, K80595 |
| SUSPENSIA | X50BJ0064 |
| SYD | 1025016 |
| TRW | JBJ933, JBJ954 |
| Toyota | 4333009670, 4333029425 |
| XRF | K500040, K80595 |
| XRF Chassis | K500040, K80595 |
DORMAN BJ74305 Fits Vehicles
- Toyota Corolla (2009-2019)
- Pontiac Vibe (2003-2010)
- Toyota Matrix (2003-2014)
- Scion tC (2005-2010)
