RAYBESTOS 580759FZN Part Description
Manufacturer
Product Description
Raybestos Element3 Coated Brake Rotor
Application Summary
2016-2010 Cadillac SRX Rear, 2011 Saab 9-4X Rear
Features & Benefits
- Grey Fusion 4.0(R) Coating
- Grey Fusion 4.0® Coating
- Grey Fusion 4.0(R) coating provides optimal corrosion resistance and faster brake jobs.
- Grey Fusion 4.0® coating provides optimal corrosion resistance and faster brake jobs.
- RPT(R) Rust Prevention Technology
- RPT® Rust Prevention Technology
- RPT(R) Rust Prevention Technology for long lasting rust prevention.
- RPT® Rust Prevention Technology for long lasting rust prevention.
- Cooling Vanes
- Cooling vanes are coated to ensure vanes remain clear of rust and corrosion for optimal airflow and cooling.
- OE Matched
- OE Matched precision and performance.
- Non-Directional Finish
- A non-directional ground finish provides a product that is ready to install right out of the box.
RAYBESTOS 580759FZN Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.65 IN |
| Center Hole Diameter | 67.3 MM |
| Conventional Or Drum-In-Hat Type Rotor | Drum-In-Hat |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Discard Thickness | 0.847 IN |
| Discard Thickness | 21.5 MM |
| Harmonize Code | 8708.30.5030 |
| Inside Diameter | 9.075 IN |
| Inside Diameter | 230.5 MM |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 4.72 IN |
| Mounting Bolt Hole Circle Diameter | 119.9 MM |
| Mounting Bolt Hole Diameter | 0.625 IN |
| Mounting Bolt Hole Diameter | 15.9 MM |
| Mounting Bolt Hole Quantity | 6 |
| Nominal Thickness | 0.906 IN |
| Nominal Thickness | 23 MM |
| Outside Diameter | 12.402 IN |
| Outside Diameter | 315 MM |
| Overall Height | 1.89 IN |
| Overall Height | 48 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 6 |
| Surface Type | Smooth |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00887213288087 |
RAYBESTOS 580759FZN Cross References
| Brand | Part Number |
|---|---|
| ADVANCE AUTO PARTS | YH290682, YH290682C, YH290682P |
| ADVICS | L6R189U |
| AUTOPARTSOURCE | 493114 |
| AUTOXTRA | AX900842 |
| AUTOZONE | 72017 |
| AutoZone | 72017DG |
| BENDIX | PRT5972 |
| BRAKEBEST | 580759, 580759R, 580759RGS |
| CENTRIC | 120.62123, 121.62123, 126.62123SL, 126.62123SR, 127.62123L, 127.62123R, 320.62123 |
| Centric Parts | 120.62123, 121.62123, 126.62123SL, 126.62123SR, 127.62123L, 127.62123R, 320.62123 |
| DURA CORP | BR55176, BR900842 |
| DuraGo | 900842, BR900842 |
| GM | 13501317 |
| General Motors | 13501317 |
| NEWTEK AUTOMOTIVE | 55176 |
| Newtek Automotive USA | 55176 |
| POWERSTOP | AR82143EVC |
| PROMAX | 14-55176 |
| QUALIS | 41259 |
| TopNotch | TN580759GEO |
| UAP | 2055176, 55176 |
| WAGNER BRAKE | 55176, BD180463 |
| WINHERE | 6621225 |
| WORLDPAC | 1407-290682 |
| WORLDPARTS | WS1-155176 |
| Wagner Brake | BD180463E |
RAYBESTOS 580759FZN Fits Vehicles
- Saab 9-4X (2011)
- Cadillac SRX (2010-2016)
