(888) 312-8812 Login SignupRAYBESTOS 980532R Raybestos R-Line Brake Rotor
$9399
Limited availability at this price!
1 Day Lead Time
Get it by Monday, Mar 23
RAYBESTOS 980532R Part Description
Manufacturer
Product Description
Raybestos R-Line Brake Rotor
Application Summary
2012-2006 Land Rover Range Rover Front
Features & Benefits
- OE Fit, Form, and Function
- Developed from OE samples and made with G3000-qualified material, ensuring OE fit, form and function for dependable braking.
- SAE Standard
- R-Line Rotors meet the SAE standard for tensile strength, providing structural integrity and a maximum service life.
- Low Initial Lateral Runout and Thickness Variation
- R-Line Rotors have a small parameter lateral runout and a thickness variation ensuring less pedal pulsation, less brake noise, and an extended pad life.
- Mill Balanced Edges
- R-Line Rotors are mill balanced and 100 percent validated. This helps minimize the thickness variation on the rotor and leads to minimized vibration and smoother stopping.
RAYBESTOS 980532R Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 3.11 IN |
| Center Hole Diameter | 79 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 1.063 IN |
| Discard Thickness | 27 MM |
| Harmonize Code | 8708.30.5030 |
| Mounting Bolt Hole Circle Diameter | 4.724 IN |
| Mounting Bolt Hole Circle Diameter | 120 MM |
| Mounting Bolt Hole Diameter | 0.65 IN |
| Mounting Bolt Hole Diameter | 16.5 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 1.181 IN |
| Nominal Thickness | 30 MM |
| Outside Diameter | 14.173 IN |
| Outside Diameter | 360 MM |
| Overall Height | 3.189 IN |
| Overall Height | 81 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00887213286601 |
RAYBESTOS 980532R Cross References
| Brand | Part Number |
|---|---|
| ADVANCE AUTO PARTS | YH200922P |
| AUTOZONE | 45430, 45430DG |
| Advance Auto Parts | YH200960 |
| BENDIX | PRT5935 |
| BOSCH | 44011165 |
| BRAKEBEST | 980532, 980532RGS |
| BREMBO | 09.9372.21 |
| CENTRIC | 120.22015, 121.22015, 125.22020CRY, 125.22015, 125.22015CRY, 126.22015CSL, 126.22015CSR, 126.22015SL, 126.22015SR, 127.22015L, 127.22015R, 128.22015CL, 128.22015CR, 128.22015L, 128.22015R, 320.22015H |
| Centric Parts | 120.22015, 121.22015, 125.22015, 125.22015CRY, 125.22020CRY, 126.22015CSL, 126.22015CSR, 126.22015SL, 126.22015SR, 127.22015L, 127.22015R, 128.22015CL, 128.22015CR, 128.22015L, 128.22015R, 320.22015H |
| DURA CORP | BR34337 |
| Dura Corp | BR901334 |
| DuraGo | BR901334 |
| LAND ROVER | LR031843, SDB500193 |
| MAGMA PRODUCTS | PMR345037 |
| N/A | 120.22020, 121.22020, 125.22020, 126.22020SL, 126.22020SR, 127.22020L, 127.22020R, 128.22020L, 128.22020R |
| NAPA BRAKES | SDK6548 |
| NEWTEK AUTOMOTIVE | 34337 |
| Newtek Automotive USA | 34337 |
| POWERSTOP | EBR815EVC |
| PROMAX | 14-34337 |
| Qualis | 45430 |
| UAP | 34337 |
| WAGNER BRAKE | BD180078 |
| WINHERE | 6620987 |
| WORLDPAC | 1407-75767, 1427-731894 |
| Wagner Brake | BD180078E, BD180825E |
RAYBESTOS 980532R Fits Vehicles
- Land Rover Range Rover (2006-2012)
