(888) 312-8812 Login SignupFLEETGUARD LF695 Engine Oil Filter - 6.64 in. Height, 4.24 in. (Largest OD), Thermo-King 113746
Tap to view 1 more
$3349
Limited availability at this price!
In Stock
Get it by Thursday, Mar 5
FLEETGUARD LF695 Part Description
FLEETGUARD LF695 Specifications
Product Attributes
| Height | 6.64 in. (168.66 mm) |
| Micron Rating | 95 percent at 30 Microns |
| Gasket Inside Diameter | 2.45 in. (62.23) |
| Gasket Outside Diameter | 2.81 in. (71.37) |
| Notes | Spin-On |
| Outside Diameter (Largest) | 4.24 in. (107.7 mm) |
| Seam Outside Diameter | 4.24 in. (107.7) |
| Standpipe | NO |
| Thread Size | 3/4-20 UNEF-2B |
| Largest Od | 4.239 in |
| Overall Height | 6.636 in |
| Gasket Inside Diameter | 2.4641683000000003 IN |
| Gasket Outside Diameter | 2.8200731 IN |
| Height | 6.635830355 in |
| Largest Outside Diameter | 4.2389679000000005 IN |
| Gasket Inside Diameter | 2.4641683000000003 IN |
| Gasket Outside Diameter | 2.8200731 IN |
| Height | 6.635830355 in |
| Largest Outside Diameter | 4.2389679000000005 IN |
Additional Information
| Warranty Distance | 100000 |
| Warranty Distance UOM | DH |
| Warranty Time | 1 |
| Warranty Time UOM | YR |
| UPC | 00638217109621 |
FLEETGUARD LF695 Cross References
| Brand | Part Number |
|---|---|
| FGLF695, HK4Z9966600DB | |
| AC | PF895 |
| BALDWIN | B128 |
| Baldwin | 15326 |
| Big A | 2033, 92802 |
| CARQUEST | 85802 |
| Caterpillar | 9Y4485 |
| Champ | LFP3746, PH3746 |
| Coopers | LSB5035 |
| Cyclone | PM517 |
| Donaldson | LFP553746, P553746, P779155 |
| FRAM | P3340 |
| GMC | 25010066 |
| Gonher | GP67, GP67M |
| Hastings | LF435, P435 |
| Kralinator | L143 |
| LUBER-FINER | LFP3746, LP5015 |
| Motorcraft | FL762, FL762FP |
| N/A | LFP170046, SP580, 20115703, 3I1277, 25010066, 3076P3340, SO695 |
| NAPA | 1802 |
| Purolator | 6701901, L40128, PER128 |
| THERMO-KING | 113746 |
| Thermo-King | 115703, 123746 |
| Transicold | 20115703 |
| WIX FILTERS | 51802 |
| Wix | 51802 |
FLEETGUARD LF695 Customer Reviews
No reviews yet
Be the first to review this product!
FLEETGUARD LF695 Manufacturer Information
Since 1987, Fleetguard® has been one of the world's leaders in filtration solutions for both on- and off-highway applications. Whether it's air, fuel, oil, or hydraulic filtration, Fleetguard filters provide superior protection against contaminants for engines and sensitive equipment in the agriculture, construction, commercial vehicle, marine, mining, and power generation industries. Each filter is fitted with high-quality filter media for longer service life as well as a more compact design to accommodate shrinking engine compartments found in modern vehicles. All products also undergo extensive performance tests and strict quality control procedures to ensure durability and consistent performance, even in the most demanding operating conditions.
