(888) 312-8812 Login SignupFLEETGUARD LF3324 Engine Oil Filter - 5.69 in. Height, 3.67 in. (Largest OD), Full-Flow Spin-On
Tap to view 1 more
SHIPS TODAY
MSRP: $18.67
$1399
Save $4.68
Limited availability at this price!
In Stock
Get it by Friday, Feb 13
FLEETGUARD LF3324 Part Description
FLEETGUARD LF3324 Specifications
Product Attributes
| Height | 5.69 in. (144.53 mm) |
| Micron Rating | 95 percent at 30 Microns |
| Gasket Inside Diameter | 2.46 in. (62.48 mm) |
| Gasket Outside Diameter | 2.83 in. (71.88 mm) |
| Notes | Full-Flow Spin-On |
| Outside Diameter (Largest) | 3.67 in. (93.22 mm) |
| Seam Outside Diameter | 3.78 in. (96.01 mm) |
| Standpipe | NO |
| Thread Size | 3/4-16 UNF-2B |
| Largest Od | 93.22 mm |
| Overall Height | 5.69 in |
| Gasket Inside Diameter | 2.4618061 IN |
| Gasket Outside Diameter | 2.8338526 IN |
| Gasket Inside Diameter | 2.4618061 IN |
| Height | 5.690160553 in |
| Largest Outside Diameter | 3.7830633000000002 IN |
| Gasket Outside Diameter | 2.8338526 IN |
| Gasket Inside Diameter | 2.4618061 IN |
| Height | 5.690160553 in |
| Gasket Outside Diameter | 2.8338526 IN |
| Largest Outside Diameter | 3.7830633000000002 IN |
| Height | 5.690160553 in |
| Largest Outside Diameter | 3.7830633000000002 IN |
Additional Information
| Warranty Distance | 100000 |
| Warranty Distance UOM | DH |
| Warranty Time | 1 |
| Warranty Time UOM | YR |
FLEETGUARD LF3324 Cross References
| Brand | Part Number |
|---|---|
| FGLF3324, F65Z18A927AA | |
| BALDWIN | B118 |
| Bomag | 5821206 |
| CHAMP FILTERS | PH8A |
| Donaldson | P779204 |
| FRAM | PH8A, DG3985, TG8A, XG8A, DL8A |
| Fiat | 1354823 |
| General Motors | 7984655 |
| Guardian | G051452 |
| Hastings | LF518 |
| ISUZU | 132012 |
| Isuzu | X1320002, X13201002 |
| LUBER-FINER | PH8A |
| Mann-Filter | W94021 |
| N/A | 045120317630N, WL7075, 5009232, VOE13281611, S3103R, C221, VOF14 |
| Opel | 3448991 |
| PUROLATOR | L30119 |
| WIX FILTERS | WIX FILTERS, 51452MP, 51452 |
| Wix | 51452 |
FLEETGUARD LF3324 Customer Reviews
No reviews yet
Be the first to review this product!
FLEETGUARD LF3324 Manufacturer Information
Since 1987, Fleetguard® has been one of the world's leaders in filtration solutions for both on- and off-highway applications. Whether it's air, fuel, oil, or hydraulic filtration, Fleetguard filters provide superior protection against contaminants for engines and sensitive equipment in the agriculture, construction, commercial vehicle, marine, mining, and power generation industries. Each filter is fitted with high-quality filter media for longer service life as well as a more compact design to accommodate shrinking engine compartments found in modern vehicles. All products also undergo extensive performance tests and strict quality control procedures to ensure durability and consistent performance, even in the most demanding operating conditions.
