(888) 312-8812 Login SignupDELPHI TC2443 Ball Joint
Tap to view 8 more
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
DELPHI TC2443 Part Description
DELPHI TC2443 Specifications
Product Attributes
| Item Grade | Standard Replacement |
| Position(s) | Front Upper |
| Material | Steel |
| Maximum Outside Diameter | 2.165 IN |
| Maximum Outside Diameter | 55.00 MM |
| Color | Gray |
| Stud Thread Diameter | 14 MM |
| Castle Nut Included | No |
| Grease Fitting Included | No |
| Suspension Grade Type | Standard |
| Bushings Included | No |
| Dust Boot Included | Yes |
| Ball Joint Assembly | Yes |
| Width | 55 MM |
| Cotter Pin Included | No |
| Cotter Pin Hole | No |
| Mounting Hardware Included | Yes |
| Washers Included | Yes |
| Height | 4.882 IN |
| Nuts Included | Yes |
| Adjustable | No |
| Greaseable | No |
| Stud Thread Length | 1.161 IN |
| Stud Type | Threaded |
| Mounting Type | Press-In |
| Dust Boot Material | Rubber |
| Mounting Bolts Included | No |
| Mount Plate Included | No |
| Tapered Stud | Yes |
| Stud Taper Per Foot | 0.167 IN |
| Stud Tapered End 2 Diameter | 0.669 IN |
| Stud Tapered End 2 Diameter | 17 MM |
| Stud Tapered End 1 Diameter | 0.783 IN |
| Stud Tapered End 1 Diameter | 19.9 MM |
| Stud Thread Pitch | 1.5 MM |
| Length | 124.00 MM |
| Length | 4.880 IN |
| Stud Thread Diameter | 0.55 IN |
| Height | 124.00 MM |
| Stud Thread Length | 29.49 MM |
Additional Information
| Harmonized Tariff Code (HTS) | 8708806590 |
| Harmonized Tariff Code (Schedule B) | 8708807000 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| Country of Origin (Primary) | TR |
| UPC | 00689604301760 |
| VMRS Code | 016001014 |
| UNSPSC | 25174203 |
DELPHI TC2443 Cross References
DELPHI TC2443 Fits Vehicles
- Ram 1500 (2011-2019)
- Dodge Ram 1500 (2006-2010)
