RANCHO RS55836 Part Description
Manufacturer
Product Description
RS5000X Suspension Strut
Features & Benefits
- IMPROVED HANDLING AND PERFORMANCE -- Cross Tuned technology featuring exclusive rebound valving system and advanced compression phase improves overall handling and performance on and off road
- MINIMIZES ROUGH RIDE -- Exclusive Progressive Engagement Valving is custom-tuned for each vehicle to help reduce initial impacts at low speeds and minimizes a rough ride
- STRONG AND DURABLE -- Features a nitro-carburized piston rod to resist scuffs & corrosion, double-welded loops at stress areas, application-specific sintered iron piston for enhanced structural integrity and polyvinyl protective boot
- HANDLES EXTREME TEMPERATURE CHANGES -- Large twin-tube body filled with all-weather fluid allows for cooler operation, increased vehicle control and ability to withstand internal temperatures of -40 to 248degF
- HANDLES EXTREME TEMPERATURE CHANGES -- Large twin-tube body filled with all-weather fluid allows for cooler operation, increased vehicle control and ability to withstand internal temperatures of -40 to 248°F
- SMOOTH PERFORMANCE -- Polyurethane rebound bumper and rubber bushings help absorb ride harshness while the fluon-banded piston enhances responsiveness to changing road conditions for an overall smoother ride
- REDUCES FADE -- Nitrogen gas pressurized to 60 PSI to minimize air-to-oil mixture to reduce damping performance fade and foaming
- MAINTAINS VEHICLE CONTROL -- Compression Control Valve is custom-tuned for each vehicle to regulate fluid transfer to absorb impacts without disc flutter and help maintain shock motion control
- BUILT TO LAST -- Low-friction, self-lubricating seal retains gas and oil for quicker rebound and smoother compression while the application-specific piston delivers heightened control of shock motion due to the expanded piston area
- BUY WITH CONFIDENCE -- Comes with Rancho's Limited Lifetime Warranty
- BUY WITH CONFIDENCE -- Comes with Rancho’s Limited Lifetime Warranty
RANCHO RS55836 Specifications
Product Attributes
| Body Type | SS7 |
| Compressed Length | 17.18 IN |
| Travel Length | 4.43 in |
| Grade Type | Performance |
| Extended Length | 21.63 in |
| Upper Mount Type | XP15 |
| Gas Charged | Yes |
| Body Length | 16.68 IN |
| Adjustable Damping | No |
| Dust Shield Included | No |
| Includes Bump Stop | No |
| Internal Rebound Bumper | Yes |
| Finish | Painted |
| Hydraulic Lockout | No |
| Lower Mount Type | Loop Bushing Mount - 5/8" Bushing ID X 1.5/16" Bushing OAL |
| Parts Pack(s) | P01726 |
| Upper Mount Code | XP15 |
| Compressed Length | 436.4 MM |
| Extended Length | 549.4 MM |
| Travel Length | 112.5 MM |
| Body Length | 423.7 MM |
| Lower Mount Type | Loop (Eyelet) Bushing |
Additional Information
| Country of Origin (Primary) | US |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708801600 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| MSDS Sheet Number | 01164 |
| UPC | 00039703006279 |
| VMRS Code | 016020000 |
| UNSPSC | 25172007 |
RANCHO RS55836 Cross References
| Brand | Part Number |
|---|---|
| Autopart International | 2701635329 |
| BILSTEIN | 24-255103, 24-337090 |
| FCS | 345837 |
| Ford | FL3Z18124D, FL3Z18124F, FL3Z18124G, JL3Z18124D, JL3Z18124F, JL3Z18124G, JL3Z18124J |
| KYB | 3410022 |
| MONROE | 73032 |
| Monroe Shocks & Struts | 72652, 73032 |
| Motorcraft | ASH24611, ASH24613, ASH24743, ASH24745, ASH24746, ASH85878 |
| NAPA Shocks | 73032, 72652 |
| PM Auto | PM6001369 |
| PRT | 370787 |
| Pro Comp Suspension | ZX2118 |
| WALKER EXHAUST | 73032 |
RANCHO RS55836 Fits Vehicles
- Ford F-150 (2014-2020)
