(888) 312-8812 Login SignupQuick-Strut Suspension Strut and Coil Spring Assembly
| Compressed Length | 12.519 IN |
| Extended Length | 16.437 in |
| Travel Length | 3.92 in |
| Body Length | 11.496 IN |
| Gas Charged | Yes |
| Parts Pack(s) | P01101 |
| Mounting Hardware Included | YES |
| Compressed Length | 318 MM |
| Extended Length | 417.5 MM |
| Travel Length | 99.5 MM |
| Body Length | 292 MM |
| Includes Bump Stop | No |
| Grade Type | Premium |
| Active or Passive Suspension | Passive |
| Adjustable Compression | No |
| Adjustable Ride Height | No |
| Strut Mount(s) Included | Yes |
| Strut Mount Insulator(s) Included | Yes |
| Coil Spring Included | Yes |
| Coil Spring Insulator(s) Included | Yes |
| MSDS Sheet Number | 01168 |
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708801910 |
| Harmonized Tariff Code (Schedule B) | 8708800050 |
| Harmonized Tariff Code (HTS) | 8708801300 |
| UPC | 00048598212306 |
| VMRS Code | 016020006 |
| UNSPSC | 25172007 |
| Brand | Part Number |
|---|---|
| AutoZone | LS5391791R |
| Duralast | LS5391791R |
| FCS | 1345411R, 1345566R |
| FCS Auto Parts | 1345411R, 1345566R |
| GSP AUTO PARTS NORTH AMERICA INC | 882515 |
| KYB | SR4133, SR4463, SR4470, SR4463K, SR4612 |
| MANDO | MSS052008X, MSS052008A |
| MasterPro Shocks and Struts | 33TY1200 |
| NAPA Shocks | 271105 |
| Toyota | 4851009F40, 4851009L80, 4851009L81, 4851009L90, 4851009U50, 4852009F00, 4853009B50, 4853009E40, 4853009Q40, 4853009Q92, 4854009530 |
| UNITY AUTOMOTIVE | 11568, 2-11567-11568-001 |
